INA VSI 250955 N Slewing Bearing Replacement
Level 3 VerifiedMERYDOM manufactures an engineering-verified replacement for the INA VSI 250955 N slewing bearing. The replacement is reviewed against the available dimensional, mounting and product-interface data for this reference.
The INA VSI 250955 N reference belongs to the Vsi 25 Series and uses a four-point contact ball, internal gear slewing bearing configuration.
MERYDOM BRAND · CERTIFIED REPLACEMENTCertified product dataView complete specifications ↓ Factory assurance
VSI 250955 N
MERYDOM VerifiedLevel 3 · Engineering verification recordMERYDOM-manufactured slewing bearing certified for interchange with INA VSI 250955 N.
- Overall OD (Do)
- 1055 mm
- Overall ID (di)
- 810 mm
- Overall height
- Not published
- Gear arrangement
- Internal gear
- Mounting holes
- 30 / 30 outer / inner
- Bearing design
- Four-point contact ball
- Certified dimensional interchange
- MERYDOM controlled materials
- Factory documentation available
PRODUCT DIMENSIONS
View complete specifications ↓Published dimensions and interfaces
Every available catalog dimension, mounting interface and gear value is shown here in the original published unit.
Dimensions
- Mass (Mass)
- 149 kg
- Overall outside diameter (Da)
- 1,055 mm
- Outside centring diameter (DaZT)
- 1,053 mm
- Overall inside diameter (di)
- 810 mm
- Catalog diameter Di (Di)
- 953 mm
- Catalog diameter da (da)
- 957 mm
- Catalog centring diameter daZT (daZT)
- 955 mm
Mounting
- Outer ring bolt circle (La)
- 1,015 mm
- Inner ring bolt circle (Li)
- 894 mm
- Common mounting-hole count (nB)
- 30
Gear
- Gear pitch diameter (d0)
- 830 mm
- Gear module (m)
- 10 mm
- Gear tooth count (z)
- 83
MERYDOM CERTIFIED SPECIFICATION
MERYDOM Factory Verified · Controlled recordINA VSI 250955 N Slewing Bearing Specifications
MERYDOM product identity, certification, materials and dimensional data for the certified replacement.
| Technical parameter | MERYDOM certified product value |
|---|---|
| MERYDOM Certified Product | |
| Product brand | MERYDOM |
| MERYDOM model | VSI 250955 N |
| Certified interchangeable with | INA VSI 250955 N |
| Factory verification | Level 3 · Engineering Verified |
| Reviewed by | MERYDOM Engineering Department |
| Verification metadata | Controlled internal record; date and drawing revision are not published. |
| Materials | |
| Configurable ring material options | 42CrMo / 50Mn |
| Seal material | NBR · Nitrile rubber |
| Configurable spacer material options | Engineering nylon / Brass |
| Identification | |
| Reference brand | INA |
| Series | Vsi 25 Series |
| Reference model | VSI 250955 N |
| System of measurement | Metric |
| Bearing structure | Four-point contact ball |
| Gear arrangement | Internal gear |
| Dimensions | |
| Mass (Mass) | 149 kg |
| Overall outside diameter (Da) | 1,055 mm |
| Outside centring diameter (DaZT) | 1,053 mm |
| Overall inside diameter (di) | 810 mm |
| Catalog diameter Di (Di) | 953 mm |
| Catalog diameter da (da) | 957 mm |
| Catalog centring diameter daZT (daZT) | 955 mm |
| Mounting | |
| Outer ring bolt circle (La) | 1,015 mm |
| Inner ring bolt circle (Li) | 894 mm |
| Common mounting-hole count (nB) | 30 |
| Gear | |
| Gear pitch diameter (d0) | 830 mm |
| Gear module (m) | 10 mm |
| Gear tooth count (z) | 83 |
| Ratings | |
| Maximum permissible radial load (Fr perm) | 363.3 kN |
| Normal tooth force (Fznorm) | 68 kN |
| Maximum tooth force (Fzmax) | 98.9 kN |
| Basic dynamic axial load rating (Ca) | 500 kN |
| Basic static axial load rating (C0a) | 2,850 kN |
| Basic dynamic radial load rating (Cr) | 330 kN |
| Basic static radial load rating (C0r) | 1,280 kN |
| Radial clearance (Radial clearance) | 0,03 incl. 0,13 mm |
| Axial tilting clearance (Axial tilting clearance) | 0,05 incl. 0,24 mm |
Level 3 · MERYDOM Engineering VerifiedReviewed by MERYDOM Engineering Department. Evidence date and drawing revision are not published.
SERIES LOAD CAPACITY
Vsi 25 Series load chart
Use the model designation in the catalog legend as an initial moment-and-thrust capacity reference.
Engineering selection note
This catalog chart is a preliminary selection aid. Final MERYDOM application approval must also consider mounting rigidity, bolt capacity, duty cycle, lubrication and operating conditions.
MERYDOM ENGINEERING
MERYDOM Replacement for INA VSI 250955 N
This MERYDOM bearing has been reviewed against the published model envelope, mounting interfaces, gear configuration and declared material specification for replacement use.
MERYDOM construction
- Configurable 42CrMo or 50Mn ring material options
- NBR nitrile-rubber sealing system
- Configurable engineering nylon or brass spacer options
Factory documentation
- Engineering verification by MERYDOM Engineering Department
- Verification evidence is maintained in the controlled internal record
- Drawing revision and final documentation package are confirmed with the quotation
Application confirmation
- Confirm support flatness, bolt grade and preload
- Verify applied loads, duty cycle and lubrication
- Confirm temperature, environment and installation conditions
